• Chief K3G120B KONTOUR K3 Grommet Mounted 1×2 Array


  Flexibility meets form and function with the Kontour™K3 series of elegantly designed static multi-monitor array mounts from Chief.
  K3 products provide an aesthetic, stable solution for use in a variety of multi-monitor applications: call centers, control rooms, financial services, gaming, health care, IT, security desks, and others.
  Most K3 series configurations are available as free standing or grommet/bolt through mounts. The KRA500 Desk Clamp accessory is also available for most K3 series array mounts.

  Flexible multi-monitor array mounts available in configurations from dual up to six displays
  Products ship largely pre-assembled for fast installation
  Tool-free integrated cable management
  Independent height, pan, & tilt adjustment of each display for flexible monitor positioning
  Free-standing or grommet mounting styles, with optional desk clamp accessory
  Streamlined modern aesthetic
  Majority of Kontour™ K3 products are TAA-compliant

• Dimensions & Measurements
  Depth	17.8 cm (7 in)
  Height	98.6 cm (38.8 in)
  Overall Dimensions	38.81″ x 7.55″ x 7.02″ (985.8 x 191.8 x 178.2mm)
  Shipping Weight	8.6 kg (19 lbs)
  Typical Screen Size	Up to 30″ (762mm)
  Weight Capacity	11.3 kg (25 lbs)
  Width	19.2 cm (7.6 in)

  Characteristics & Features
  Adjustability	Height Adjustable
  Tilt	Yes (+/- 10° vertical tilt)
  Application	Grommet Mount
  Array Configuration	1×2
  Color	Black
  Desktop Thickness Range	0.5″ – 5″ (13mm – 127mm)
  Grommet Hole Size Range	0.38″ – 3.5″ (10mm – 89mm)
  Notes	Weight capacity is per monitor
  Number of Displays	2
  Orientation	Landscape, Portrait
  Post-Installation Leveling Roll	Yes
  Solution Type	Universal
  Special Features	Multi-Display, Tilt
  VESA Mounting Pattern	75 x 75mm, 100 x 100mm
