• Bosch Passive Infrared (PIR) Sensor/Microwave Motion Detector


  Motion detector, 12 m, PIR, 10.51-10.58 GHz, 105x61x44 mm, 9-15V DC
  The Blue Line Gen2 TriTech Motion Detectors (ISCBDL2) use a combination of passive infrared (PIR) and microwave Doppler radar detection with advanced signal processing. The pet‑friendly (‑WP) models generate alarms for human intruders without generating false alarms for pets. These small unobtrusive detectors are simple to install and do not need field adjustments.

• Category	Feature	Details
  General Features	Certification	CE, AFNOR
  	Housing Material	ABS/Plastic
  	Installation Height (Max)	2.75 m
  	Installation Height (Min)	2.2 m
  	LED Indicators	Alarm
  	Mounting Type	Wall
  	Product Color	White
  Legal Information	UNSPSC Code (Icecat)	46171608
  Operational Conditions	Operating Humidity (H-H)	0 – 95%
  	Operating Temperature (T-T)	-20 to 55°C
  Package Dimensions	Package Height	4.8 cm
  	Package Depth (Verified)	6.4 cm
  	Package Width (Verified)	11.2 cm
  	Gross Weight (Verified)	0.11 kg
  Packaging Data	Quantity per Pack	1 pc(s)
  Power	Input Voltage	9 – 15 V
  	Power Source Type	DC
  	Standby Current	10 mA
  Product Dimensions	Net Weight (Product, kg)	0.09 kg
  	Product Depth	6.1 cm
  	Product Height	4.4 cm
  	Product Width	10.5 cm
  Security & Detection	Connectivity Technology	Wired
  	Detection Distance	12 m
  	Operating Frequency	10510 – 10580 MHz
  	Sensor Type	PIR & Microwave sensor
  Vendor Information	Brand Name	Bosch
  	Warranty	8 Years
