• BluStream DAC12AU Digital to Analogue Converter (DAC) – Simultaneous Analogue and Digital Output

  Our DAC12AU is designed to convert either coaxial or optical signals from a digital signal to analogue stereo audio.

  The DAC12AU also includes a digital converter which converts optical audio in to a coaxial digital output. This provides the perfect cost effective solution when connecting the digital audio output from a TV display to an analogue input on an amplifier.

  The DAC12AU utilises 192kHz sample rates for enhanced sound reproduction.

  Key Features
  • Digital to Analogue audio Converter converts either optical or coaxial digital to analogue stereo left / right audio output
  • Converts optical digital audio input to coaxial digital audio output
  • Auto-detects digital connection in use
  • Optical digital input has priority over coaxial digital input
  • Outputs coaxial digital and analogue L/R audio concurrently*
  • Supports sample rates 32 kHz, 44.1kHz, 48 kHz, 96 kHz & 192 kHz up to 24-bit resolution
  • Plug-and-play

  *DAC12AU does not down mix Dolby / DTS / multi-channel audio signals

  Box Contents
  1 x DAC12AU
  1 x 5V/1A DC Power Supply
  1 x Mounting Kit
  1 x User Manual

• Category	Details
  Audio Input Connectors	1 x optical digital & 1 x coaxial RCA (S/PDIF)
  Audio Output Connectors	2 x Analogue stereo left/right & 1 x Coaxial RCA (S/PDIF)
  Dimensions (W x H x D)	50mm x 26mm x 42mm
  Dimensions (including connections)	68mm x 26mm x 42mm
  Shipping Weight	0.4kg
  Operating Temperature	32°F to 104°F (0°C to 40°C)
  Storage Temperature	-4°F to 140°F (-20°C to 60°C)
  Power Supply	5V/1A DC
