BluStream 4-Way HDMI 2.0 Output Board – 18Gbps | PRO-OUT4H-V2

• Description
• Specifications

• BluStream 4-Way HDMI 2.0 Output Board – 18Gbps | PRO-OUT4H-V2

  The PRO-OUT4H-V2 supports HDMI 2.0 4K 60Hz 4:4:4 (18Gbps) with HDCP 2.2, allowing distribution of inputs to four independent displays.

  The PRO-OUT4H-V2 also features quick release card module fittings allowing simple installation into the Custom Pro Matrix hub.

  Key Features
  • Features 4 x HDMI outputs for connection to HDMI displays
  • Supports HDMI 2.0 18Gbps specification including HDR
  • Supports up to 4K UHD 60Hz 4:4:4*
  • Supports all known HDMI audio formats including Dolby TrueHD, Atmos and DTS-HD Master Audio transmission
  • Quick release card module fittings allowing simple population of input and output cards in Custom Pro Matrix Hub
  • HDCP 2.2 Support

• Feature	Specification
  Video Output Connectors	4 x HDMI Type A, 19-pin, female
  Card Dimensions (W x H x D)	182mm x 22mm x 177mm
  Dimensions Including Connections (W x H x D)	202mm x 22mm x 188mm
  Shipping Weight	0.5kg
  Operating Temperature	32°F to 104°F (0°C to 40°C)
  Storage Temperature	-4°F to 140°F (-20°C to 60°C)
