Blackmagic Micro Converter SDI to HDMI 3G | CONVCMIC/SH03G

• Description
• Specifications

• Blackmagic Micro Converter SDI to HDMI 3G


  This model has been specifically designed for professional monitoring. It includes a 17-point 3D LUT for color calibrating any monitor, projector or television. You can even output the 3D LUT on the SDI loop output! Plus it supports DCI formats and film rates, including 1080p24, 1080p47.95 and 1080p48.

• Feature	Details
  Type	3G-SDI/HD-SDI/SDI to HDMI video and audio converter
  Width	7.95 cm
  Depth	2.49 cm
  Height	4.57 cm
  Weight	150 g
  Supported Video Standards	PAL, NTSC
  Features	USB powered, 1080p60 support, auto-switching capability
  Power Consumption	1.6 Watt
  Low Voltage Power	DC 4.4 – 5.25 V
  Terminals	(1) x 3G-SDI input – BNC, (1) x 3G-SDI loop out – BNC, (1) x HDMI output – 19 pin HDMI Type A, (1) x USB-C
  Min Operating Temperature	0 °C
  Max Operating Temperature	40 °C
  Humidity Range Operating	0 – 90% (non-condensing)
  Warranty	3 years
