• Blackmagic Design SmartView Duo | HDL-SMTVDUO2

  Featuring two large independent 8 inch LCD screens in a compact rack mount design, SmartView Duo handles SD, HD and 3Gb/s SDI video standards. SmartView Duo is perfect for post production, broadcast and live event monitoring. For easy setup, all screens can be remotely adjusted via ethernet connection. With SmartView Duo you can install SDI monitoring everywhere you need!

• Feature	Details
  Connections
  SDI Video Input	1, automatically switches between SD, HD and 3G-SDI
  SDI Video Output	1 x loop out, 1 x monitor out
  Multi Rate Support	Auto detects 2K, HD or SD inputs
  Updates & Configuration	USB 2.0 high speed (480 Mb/s)
  Ethernet	10/100 BaseT with loop through
  Tally	9-pin D connector
  Standards
  SDI Compliance	Various SMPTE standards
  SDI Color Space	REC 601, REC 709
  SDI Auto Switching	SD, HD and 3 Gb/s SDI
  Video Sampling	4:2:2 and 4:4:4
  SDI Format Support	Extensive list from 525i to 1080i60
  2K Format Support	2K DCI formats at 23.98, 24, 25 fps (progressive & PsF)
  Software
  Internal Software Upgrade	Firmware updater software
  SmartView Utility Software	Via USB or Ethernet
  Operating Systems	Mac 10.15 Catalina or later, Windows 10 64-bit
  Display
  Display Element	TFT Active Matrix LCD
  Display Resolution	800 x 480 pixels
  Response Time	< 15 ms
  Contrast Ratio	Typically 500:1
  Color Depth	16.7 Million Colors
  Display Orientation	Rotatable
  Power Requirements
  Power Supply	12V universal power supply included
  Power Consumption	< 20 Watts
  Operating Voltage Range	12V – 15V
  Physical Specifications
  Environmental Specifications
  Operating Temperature	0° to 40° C (32° to 104° F)
  Storage Temperature	-20° to 45° C (-4° to 113° F)
  Relative Humidity	0% to 90% non-condensing
  What’s Included
  SmartView Duo
  Power Supply
  Welcome wallet with software download QR code
  Warranty	12 Months Limited Manufacturer’s Warranty
