• Blackmagic Design SmartView 4K | HDL-SMTV4K12G2

  The world’s first full resolution Ultra HD broadcast monitor with multi rate 12G-SDI, an extremely bright display with wide viewing angle, plus advanced broadcast features like 3D LUT support, H/V delay, blue only, adjustable frame guides and more! SmartView 4K is compatible with all SD, HD and Ultra HD formats up to 2160p60. With both AC and DC power connections, SmartView 4K can be used in broadcast studios or on set.

  SmartView 4K is the world’s first full resolution rack mount Ultra HD broadcast monitor with 12G-SDI for native display of up to 2160p60. You get a professional broadcast monitor that supports the latest Ultra HD resolutions, plus automatically switches to SD and HD-SDI formats using high quality Teranex processing for a clean and professional display. The machined metal design includes a built in control panel for using features such as the built in 3D LUTs, H/V delay, blue only, customizable frame markers and more, either from the front panel or via external Ethernet! SmartView 4K supports VESA mounting so you can install on articulated monitor arms or rack mounting.

• Category	Value
  Connections
  SDI Video Input	2x BNC (SD/HD/3G/6G/12G-SDI)
  Optical Video Input	SFP Optical Fiber connector cage
  SDI Video Output	1x BNC (reclocked output)
  Multi Rate Support	Auto detection of 4K, 2K, HD or SD
  Updates & Configuration	USB, Ethernet (Gigabit with loop through)
  Tally	9-pin D connector
  Standards
  SDI Format Support	SD, HD, Ultra HD, 4K DCI
  Video Sampling	4:2:2 and 4:4:4
  SDI Compliance	Various SMPTE standards
  SDI Color Space	REC 601, REC 709
  Software
  Internal Software Upgrade	Firmware updater software included
  Settings Control	USB or Ethernet
  Operating Systems	Mac OS X 10.9 Mavericks or later, Windows 7 & 8 (32/64-bit)
  Display
  Display Element	TFT Active Matrix LCD
  Resolution	3840 x 2160 pixels
  Response Time	25 ms
  Contrast Ratio	1000:1
  Color Depth	16.7 million colors
  Power Requirements
  Power Supply	Built-in IEC power supply, DC input for external power
  Power Consumption	24 Watts
  Environmental Specifications
  Operating Temperature	0° to 40° C (32° to 104° F)
  What’s Included
  SmartView 4K monitor
  Software SD Card
  Warranty	2 Year Limited Manufacturer’s Warranty
