• BIAMP REVAMP2120T 2-Channel 100V Bridgeable Digital Power Amplifier – 2 x 120W

  Immaculate sound performance, extremely reliable, maintenance-free this is how we would describe our latest REVAMP2120T. This 2-channel digital power amplifier provides 2 x 120 watts output power @ 100 volts or @ 4 ohms, that can easily be bridged into a powerful 240 watts @ 100 volts or 8 ohm single amplifier.The REVAMP2120T is a convection cooled class-D amplifier without built-in fans which implies that the amplifier is completely noiseless and dust-free at all times.

  The ergonomic and efficient 1U design has a galvanic separated toroidal output transformer built in to avert external influences & disturbances. During the configuration of the input gain the rear clip LED indicator can be used for a fast and easy installation. The multiple inputs and link connectors make the REVAMP2120T a versatile and installerfriendly amplifier superiour to any other in the fixed install market.

• Feature	Specification
  Dynamic Output Power 4 Ohms (in watts)	2 x 120
  Dynamic Output Power 8 Ohms (in watts)	2 x 60
  Dynamic Output Power Bridged 8 Ohms (in watts)	240
  Output Power RMS 100 Volts (in watts)	2 x 120
  Minimum Impedance Load per Channel (in ohms)	4
  Power Consumption (max) (in watts)	300
  Height – Rack Units (1U=44 mm) (in U)	1
  Depth (build in) (in mm)	230
  Power Supply	115 – 230 VAC
  Output Voltage Tappings	100 – 70 – 50 – 35 watts – 4 ohms
  Line Input Balanced	2
  Channel Separation	> 65 dB @ 1 kHz
  Frequency Response (in Hz)	50 – 20 kHz
  Applicable in 100V	Yes
  Net Weight Product (kg)	6.1
  RMS Output Power 4 Ohms (in watts)	2 x 120
  RMS Output Power 8 Ohms (in watts)	2 x 60
  Output Power RMS Bridged 8 Ohms (in watts)	240
  Output Power RMS Bridged 100 Volts (in watts)	240
  Minimum Impedance Load Bridged per Channel (in ohms)	8
  19″ (483 mm wide) Rack Mounting	Yes
  Height (in mm)	44
  Depth (incl front) (in mm)	239
  Power Supply Technology	Switching mode power supply
  Output Channels	2
  Line Input Unbalanced	2
  Power Amp Topology	Class-D
  Cooling System	Convectional
  Applicable Low Impedance	Yes

• 913.0653.900 : Datasheet
