BIAMP Desono P6 Two-Way 6.5″ Pendant Mount Loudspeaker Black
Key Features
Traditional “raindrop” profile
6-ohm nominal impedance
90° coverage angle
6-position constant voltage tap (1.875W, 3.75W, 7.5W, 15W, 30W, 60W) with low impedance bypass
Bridge-mounted 1-inch (25mm) soft dome tweeter
6.5-inch (165mm) polypropylene woofer mechanically isolated from the high frequency driver
CE marked, UL listed, and RoHS compliant
5-year warranty
Desono™ P6 is a two-way passive coaxial loudspeaker intended for full range music reproduction in distributed audio applications. It delivers high intelligibility coupled with a wide coverage area, allowing system designers to use fewer speakers while maintaining superior levels of speech intelligibility.
The P6 utilizes a 6-position switchable transformer ranging from 1.875W to 60W with low-impedance bypass for 70V/100V operation, making it an excellent choice for large areas of BGM.
Designed with the installer in mind, the P6 also comes pre-terminated with Magic Cable, a composite cable comprised of two aircraft cables, two audio conductors jacketed separately, and two ripcords for slicing through the cable jackets.
Desono P6 is designed for outdoor splash applications such as patios or concourses, and an ideal choice for both indoor and outdoor distributed audio applications that demand superior speech intelligibility and full range music reproduction. -
Specification Description Height 15.6 inches (397 mm) Diameter 9.4 inches (238 mm) Weight 11 lbs (5.0 kg) Finish RAL Color: Black RAL 9005 Operating Environment IP54 per IEC 60529 Power 60W Continuous, 240W Peak Loudspeaker Type Two-way 6.5-inch pendant mount loudspeaker Operating Range 75 Hz – 18.5 kHz Transformer 70V: 60W, 30W, 15W, 7.5W, 3.75W, 1.875W; 100V: 60W, 30W, 15W, 7.5W, 3.75W Sensitivity (1W/1m) 86 dB Dispersion 90° conical Drivers LF 1 x 6.5″, HF 1 x 1″ Impedance 6Ω Maximum Output @1m: 104 dB, 110 dB Peak Zoom Zoom Certified Certifications UL1480A, CSA C22.2#62368-1, CSA C22.2#60950-22, Magic Cable: UL13, Class 3 -
Description Downloads BIAMP Desono P6 Two-Way 6.5″ Pendant Mount Loudspeaker Black | 911.0921.900 DataSheet Downloads
