• Biamp Desono DP8 Two-Way 8-inch High Output Pendant Mount Loudspeaker Black


  Highlights
   High intelligibility with wide dispersion, uniform voicing.
   Stylish contemporary design.

  Overview
  The DP8 is a high performance 8-inch pendant loudspeakers designed for open architecture spaces or any location where a stylish pendant form factor is desired. Featuring high power handling, higher sensitivity and realistic sound reproduction, the DP8 is the more focused big brother to the DP6. D SERIES pendant loudspeakers can be used in a wide variety of speech and music applications. They are equipped with a built-in autoformer, supporting low impedance or 70V/100V operation. Uniform voicing means that the DP8 can be combined with other ceiling and surface mount models in the C or D SERIES family without compromising consistency from zone to zone. The genuine coaxial design uses separate magnets for the LF and HF drivers for reduced distortion and industry-leading sensitivity, thereby permitting 3 dB to 6 dB greater output level while requiring half the amplification power of competing products. An easy-access selector switch is conveniently located on the face of the loudspeaker for selectable 8 ohm or 70V/100V operation, while an integrated rear cover hides all wiring and hanging hardware for an aesthetically pleasing installation.

• Specification	Description
  Finish	Black or white paintable ABS matte plastic, dual-layer powder-coated steel grille.
  Nominal Beamwidth (H x V)	115° Conical
  70V/100V Autoformer	120W, 60W, 30W, 15W (@70V only)
  Continuous Max Output	117 dB (123 dB Peak)
  Power Handling	150W continuous @ 8 ohms
  Operating Range	60Hz – 22 kHz
  Sensitivity (1W/1m)	95 dB
  Dimensions (H x Dia)	17.7″ x 13.4″ (450 x 341 mm)
  Transducers	LF – 1 x 8”, HF – 1 x 1.25” exit compression driver
  Warranty	5 Years
