Biamp Desono DP6-W 6.5″ Pendant Loudspeaker | 911.0551.900
The DP6 is a high performance 6.5-inch pendant loudspeaker designed for open architecture spaces or any location where a stylish pendant form factor is desired. Featuring high power handling, high sensitivity and realistic sound reproduction, D SERIES pendant loudspeakers can be used in a wide variety of speech and music applications. They are equipped with a built-in autoformer, supporting low impedance or 70V/100V operation. Uniform voicing means that the DP6 can be combined with other ceiling and surface mount models in the C or D SERIES family without compromising consistency from zone to zone. The genuine coaxial design uses separate magnets for the LF and HF drivers for reduced distortion and industry-leading sensitivity, thereby permitting 3 dB to 6 dB greater output level while requiring half the amplification power of competing products. An easy-access selector switch is conveniently located on the face of the loudspeaker for selectable 8 ohm or 70V/100V operation, while an integrated rear cover hides all wiring and hanging hardware for an aesthetically pleasing installation.
-
Category Feature Specification GENERAL Height 14.73 inches (374.2 mm) Width 11.22 inches (285 mm) Weight 11.8 lbs (5.4 kg) Mounting Two PHK-15 pendant hang kits with 15ft (4.5m) long 2mm (0.77″) high tensile galvanized steel wire rope suspension cables with integrated spring clips and Gripple™ brand adjustable height cable fasteners Accessories Two PHK-15 pendant hang kits Enclosure ABS plastic rear cover Rear cover ingress weather plug Required Accessories: Electronic high pass filter ENVIRONMENTAL POWER CONTROLS & INDICATORS Control Front-face wattage / low impedance selector switch LOUDSPEAKER Loudspeaker Type Two-way, full-range, coaxial pendant mount loudspeaker, 8 ohm or 70V/100V operation Operating Range 65 Hz – 22 kHz Crossover Crossover Frequency: 1.2 kHz Transformer Transformer Taps – 70V: 60W, 30W, 15W, 7.5W and low impedance; 100V: 60W, 30W, 15W Sensitivity Sensitivity (1W/1m): 94 dB SPL (125 Hz to 12.5 kHz 1/3 octave bands); 92 dB SPL (250 Hz to 4 kHz speech range) Coverage Nominal Coverage: 115º conical (1 kHz to 6 kHz); 125º conical (500 Hz to 6 kHz) Signal Processing Recommended Signal Processing: 65 Hz high pass filter Drivers LF: 1 x 6.5-inch; HF: 1 x 1-inch exit compression driver; Driver Protection: Self-resetting solid state circuit breaker AUDIO Input Connection Two 2-position Euroblock connectors Impedance Nominal Impedance: 8 ohms; Minimum Impedance: 6.9 ohms @ 210 Hz Maximum Input 100W continuous, 250W program; 28 volts RMS, 63 volts momentary peak Maximum Output 114 dB SPL / 120 dB SPL (peak 8 ohm) Frequency Response 80 Hz – 20 kHz (±5 dB) CERTIFIED SOLUTIONS Zoom Zoom Certified COMPLIANCE Safety Features Included safety cable. Each cable has an SWL of 99 lbs (45 kg); Safety Agency Ratings: EETL listed to comply with UL1480 and CSA60065; Suspension system and Gripple™ brand cable fastener listed per UL1598 and UL2239, TUV and CSA Class 3426-01 and Class 3426-81 NOTES Specification Notes Distortion – 10% Full Power: 2nd Harmonic 3rd Harmonic; 500 Hz 1.74% 1.19%; 2 kHz 1.18% 0.35%; 8 kHz 0.77% 0.04% Enclosure UL 94V-0 rated ABS plastic, matte finish, paintable Finish White Grille Powder coated steel with safety line, black or white finish, paintable Baffle Reflex loaded UL 94V-0 rated ABS Axial Q / DI 4.7 / 6.7, 500 Hz to 6 kHz -
