BenQ ST7502S 75″ 4K All-in-One Smart Signage Display with Ultra-Thin Bezels

• Description
• Specifications
• Downloads

• BenQ ST7502S 75″ 4K All-in-One Smart Signage Display with Ultra-Thin Bezels

  All-in-One Smart Signage Made for Effective Meetings and Presentations
  The ST02S upgrades enterprise, corporate and organisational conference capabilities while maintaining superb return on investment. Visuals come across in 4K ultra HD with vivid colours and sharp contrast on thin-bezel screens, putting an end to vague, blurry image quality that detracts from the impact and sheer productivity of teleconferencing.


  Successful Meetings via Optimal Clarity
  4K ultra-high definition resolution (3840 x 2160) offers the most exquisite image detail for breathtaking meeting experiences.

  True 4K UHD Details
  The ST02S is engineered to give users a more expansive canvas to showcase presentations, designs, ideas, and plans.


  Hassle-Free Video Conferencing
  Start video meetings with a simple click on the ST02S. The OPS slot-in PC is fully compatible with top video conferencing solutions such as Zoom Rooms, Microsoft Teams, Google Meet, and Cisco Webex. Also, TeamViewer Meeting is pre-installed on all ST series displays.


  All Ready for “Bring Your Own Device” with InstaShare
  Two-way mirroring and two-way touch control, plus up to four split screens supported – that’s got you covered on your favourite personal devices, so go ahead and BYOD.


  Built-In Android OS
  Saves users the need for an external device as a source for an operating system, which means more gets done directly on digital signage for increased efficacy and users’ convenience.


  Plug and Play
  Let’s you access and play multimedia files directly from a USB flash drive without requiring a PC connection or complicated set-up.


  Match your Corporate Image
  The ST02S has a friendly interface, allowing you to switch and customise the default wallpaper to show your corporate image.

  Display Management System (DMS)
  Centralised display management and the ability to keep display firmware and apps up-to-date via LAN or Internet.

  X-Sign CMS and Broadcasting Software
  Edit, manage, and customise content in depth through the intuitive X-Sign Content Management Software (CMS), included with the displays. Additionally, X-Sign Broadcast keeps teams in the know with a smart broadcasting system, which offers instant delivery and easy management of push alerts, messages and announcements.

• Category	Specification
  Screen Size	75”
  Panel Type	ADS
  Active Area	1649.7 × 927.9 mm
  Resolution	UHD 3840 × 2160 pixels
  Orientation	Landscape
  Aspect Ratio	16:9
  Panel Brightness (typical)	400 nits
  Contrast Ratio (typical)	1200:1
  Response Time	8 ms
  Color Gamut	72% NTSC
  Color Depth	8-bit
  Light Life (typical)	30,000 hrs
  System Memory/Storage	3GB
  OS	Android 8.0
  GPU	Mali-G51MP2
  CPU	A73 × 2 + A53 × 2
  Connectivity
  VGA	1
  **HDMI (in	out)**
  USB-A	2 × 2.0
  3.5mm Line In	1
  PC Audio	1
  3.5mm Line Out	Earphone × 1
  Slot-in PC (OPS)	1
  Micro SD Reader	1
  Ethernet LAN	10 / 100 Mbps (Android) × 1
  RS-232	1
  Built-in Peripherals	IR Sensor: Yes, Speaker: 2 × 10 W
  Power
  ENERGY STAR®	Yes
  Power	AC 100-240V 50/60Hz
  Standby Power Consumption	<0.5 W
  Typical Power Consumption	177 W
  Physical Dimensions	1683.5 × 961.7 × 82.9 mm (66.3 × 37.9 × 3.3 inch)
  Shipping Dimensions	1828 × 1098 × 220 mm (72.0 × 43.2 × 8.7 inch)
  Weight (Product/Shipping)	35.9 kg
  Mount (Screws)	VESA 600 × 400 mm (4 × M8 × 15L)
  Environment
  Operating Temperature	0°C ~ 40°C
  Storage Temperature	-20°C ~ 60°C
  Storage Humidity	10% ~ 80% RH non-condensing
  Operating Humidity	10% ~ 80% RH non-condensing
  Software
  Wireless Screen Sharing	InstaShare 1 (BenQ App Store)
  Device Management	DMS
  Broadcast System	X-Sign Broadcast
  Accessories
  Cables	HDMI (1.5 m
  Remote Control	1
  Panel	Viewing angle (H × V)
  Package/Accessory	User Manual, Online
