• BenQ LU960ST WUXGA Short Throw Installation Projector – 5500 Lumens

  DLP Laser Projector with Easy Maintenance
  Revolutionary Laser Technology
  Extending its full line of revolutionary laser projectors, the world’s No.1 DLP brand BenQ presents LU960ST, especially designed for short throw fixed lens installation and reserves installation flexibility to merge into limited space.

  Superior Brightness
  Zero-deviation alignment of laser diodes boosts luminous flux into the light tunnel, improving light efficacy to 5,500 ANSI lumens.

  Superior Performance
  Dual synchronized color wheels utilize an additive yellow segment, stimulating precise RGBY spectra for optimal chromatic performance.

  Superior Durability
  Comprising over two million micromirrors that reflect pure light through the color wheel, the DLP chip is hermetically sealed to resist heat for over 200,000 hours without degradation.

  DLP Technology for Long Lasting Vibrant Color
  BenQ laser projectors run on Academy Award-winning DLP technology to deliver long-lasting and reliable color for the life of the projector. The DLP chip is rated for 200,000 hours and will display stunning whites and accurate colors without the risk of yellowing over time.


  Superior Dustproofing for Severe Conditions with IP5X Certification
  BenQ laser projectors are designed with sealed laser modules and enclosed light engines to protect the DMD chip, color wheel sensor, laser package, and other optical components. This lock-and-key design hermetically seals the engine from dust to prolong projector lifespan.

  Anti-Dust Accumulation Sensor to Resist Dust Buildup
  Incorporating a color wheel sensor with an ingenious anti-dust buildup features, BenQ LU960ST prolongs optimal performance by repelling dust that can accumulate on traditional sensor to block the IR signal and cause flickering, abnormal colors, or even shutdown.

  24/7 Operation
  BenQ laser light source supports continuous 24/7 operation and is suitable for public display applications in museums and exhibitions. Users can choose from three different light source modes to optimize energy consumption and delivers up to 70,000 hours under Dimming Mode.

  High Quality Viewing Experience for Training Fidelity
  High Brightness Vivid Clarity in Bright Ambient Environments
  LU960ST’s 5500AL high brightness produces wondrous displays in bright, compact exhibition spaces with superb image quality.

  WUXGA Resolution for Enhanced Detail and Expanded Content
  With an impressive WUXGA (1920 x 1200) native resolution that far exceeds Full HD 1080p, BenQ LU960ST laser projector offers greater details and stunning image clarity when projecting high resolution images.

  Fast Mode Provide the Most In-time Visual Feedback for Your Simulator
  System latency, which is the lag between the time an operator applies an input and the simulator responds to provide both visual and motion cues, is inevitable in simulators. As a part of visual systems in simulators and based on expertise gained from experience with near-zero latency displays used in gaming, LU960ST employs a Fast Mode to provide latency as low as 16.67ms*(@WUXGA 60Hz).

  Cinematic Grade 92% Rec.709 Color Coverage for Optimal Color Performance
  LU960ST’s powerful laser projection utilizes a dual color wheel system to produce unparalleled color performance that achieves a 92% Rec.709 color coverage. By increasing color ratios and the purity of RGBY color, LU960ST dramatically enhances color saturation to ensure superior presentation quality.

  White Balance Calibration for Seamless Edge Blending
  BenQ exclusive white balance adjustments can reduce white balance variables between images projected from different projectors to such a low level that the most people cannot see any difference. This allows for seamless and accurate picture quality without disruptive discrepancies.


  Ensure Consistent Brightness Blending with Custom Light Mode
  Custom Light Mode modulates light power output from 25% to 100% at a 1% rate, optimizing the projected image in a variety of ambient lighting situations. It is especially useful for blending consistent brightness across multiple projections.

  Gamma Selection
  Select Gamma for your preference and optimizing image quality between input source and picture brightness.

  Installation Flexibility in a Compact Fixed Lens Projector

  Short Throw Design for Unobstructed Viewing Without Space Constraints
  Ideal for indoor simulation and retail applications, the LU960ST is equipped with a short-throw lens that will fill up a 12-foot-wide screen from less than 10 feet away. This enables you to place the projector so that you can stand closer to the screen without casting a shadow.

  Zoom and Lens Shift for Mounting Flexibility
  The LU960ST features both a 1.1X zoom function and vertical/horizontal lens shift to enable you to mount the projector in a protected area, while still enabling you to have a fully aligned image on your screen. You can move the image up and down up to 62% of the screen height – and adjust the horizontal position by 24% for an off-axis mounting location. The zoom lens can enlarge or reduce the image to enable you to move your mounting position as much as a foot on a fourteen-foot-wide screen.

  360° and Portrait Projection Accommodate Different Spaces
  Laser technology guarantees reliable projection from any angle. Dynamic installation options such as 360° rotation and portrait applications, allows projection onto ceiling, walls, floors or angled signage.

  Lens Lock & Metal Lens Barrel
  Most of the simulation solutions use several projectors doing blending to create a panoramic view. The Lens Lock can fix the final position, focus and zoom of the lens, avoiding the readjustment effort if any mistouching. In addition, the metal barrel lens helps the zoom and focus adjustment to be more stable and accurate comparing with plastic lens.

  3D Sync In /3D Sync out
  Connect up to 4 projectors and project 3D content together by a single PC.

  Centralized Remote Management
  DMS Local Offers Centralized Control Over Multiple Displays
  For users who would like to control all their displays remotely via LAN, you can download and install the DMS Local software for your system. DMS Local is a Device Information and Management software for use in the Windows operating system. DMS Local also supports Agent Mode which allows you to integrate your DMS Local settings to the cloud-based DMS Cloud.

  Network/Web Control
  BenQ laser projectors are compatible with Creston, AMX and PJ Link control systems for convenient system integration with various third-party components and reduced cost to centrally maintain multiple projectors.

  HDBaseT for Uncompressed Transmission Up to 100m and Control
  Groundbreaking HDBaseT connectivity combines video, audio, RS-232 and LAN signal control signals from multiple sources including: PCs, laptops, document cameras, Blu-ray and DVDs onto a single RJ-45 cable. This ensures seamless transmissions up to 100 meters.

• Category	Specifications
  Display
  Brightness (ANSI lumens)	5500
  Native Resolution	WUXGA (1920×1200)
  Native Aspect Ratio	16:10
  Contrast Ratio (FOFO)	3,000,000:1
  Display Color	30-bit (1.07 billion colors)
  Light Source	Laser
  Light Source Life	a. Normal 20000 hrs, b. ECO 38000 hrs, d. Dimming 75000 hrs
  Optical
  Throw Ratio	0.77-0.84
  Zoom Ratio	1.1x
  Lens	F/# = 1.9 ~ 1.954,f = 8.14 ~ 8.921 mm
  Projection Offset (Full-Height)	0%
  Keystone Adjustment	2D, Vertical ± 30 degrees; Horizontal ± 30 degrees
  Lens Shift Vertical	-62%~ +62%
  Lens Shift Horizontal	-24%~ +24%
  Rec. 709 Coverage	92%
  Picture Modes	3D, Bright, DICOM SIM, HDR10, HLG, Presentation, Simulator, sRGB, User 1, User 2, Video
  Compatibility
  Input Lag	8.3 ms (1080P 120Hz)
  Resolution Support	VGA (640 x 480) to 4K UHD (3840 x 2160)
  Horizontal Frequency	15K~135KHz
  Vertical Scan Rate	23~120Hz
  I/O Interface
  PC in (D-sub 15pin)	(x1), PC in-1
  Monitor out (D-sub 15pin)	(x1)
  HDMI in	(x2), HDMI-1 (2.0a/HDCP2.2), HDMI-2 (2.0a/HDCP2.2)
  Monitor out (HDMI)	(x1)
  Display Port	(x1)
  LAN (RJ45)	(x1)
  HDBaseT (RJ45)	(x1), Control/Video/Audio
  3D Sync in	(x1)
  3D Sync out	(x1)
  USB Type A	(x1), USB Type A-1 (2.0/Power Supply1.5A)
  USB Type Mini B	(x1), USB Type Mini B-1(service)
  RS232 in (DB-9pin)	(x1)
  Wired Remote in (3.5mm Mini Jack)	(x1)
  DC 12V Trigger (3.5mm Jack)	(x1)
  Audio
  Speaker	(x1), 10W
  Audio in (3.5mm Mini Jack)	(x1)
  Audio out (3.5mm Mini Jack)	(x1)
  Environment
  Operating Temperature	0~40℃
  Power Supply	AC 100 to 240 V, 50/60 Hz
  Typical Power Consumption (110V)	450W
  Stand-by Power Consumption	<0.5W
  Network Stand-by Power Consumption	<2W
  Accessories
  Remote Control w/ Battery	RCA024
  Power Cord (by region)	x1 (1.8M)
  3D Glasses	(Optional), DGD5
  Installation Guide	1 (8L)
  Warranty Card (by region)	Yes
  Dimension & Weight
  Dimensions (WxHxD) (mm)	479.6 x 182.8 x 402
  Net Weight (kg)	12
  Dimensions (WxHXD) (inch)	18.9 x 7.2 x 15.8
  Net Weight (lb)	26.46
  Projection System
  Projection System	DLP
  Optical
  Throw Ratio	0.77-0.84
  Zoom Ratio	1.1x
  Lens Shift	Vertical: ± 62 degrees‎ , Horizontal: ± 24 degrees‎
  Keystone Correction	Vertical: ± 30 degrees‎ , Horizontal: ± 30 degrees‎
  Projection Size	30″-300″
  Projection Offset	0%
  Display
  Projection System	DLP Single 0.48″ WUXGA
  DMD type	DC3 DMD Chip
  Resolution	1920 X 1200 pixels
  Brightness	5500 ANSI Lumens
  Contrast Ratio*	3,000,000:1
  Display Color	1.07 Billion Colors
  Aspect Ratio	Native 16:10 (6 aspect ratio selectable)
  Light Source	Laser diodes
  Light Source Life*	20,000/38,000/70,000 hours (Normal/Eco/Dimming)
  Audio
  Built-in Speaker	10W
  Special Feature
  Security	Security Bar,Kensington anti-theft lock slot
  Feature	Rec.709 96%, 4K Compatible, 360 Degree and Portrait Projection, Custom Lightsource Mode (light power adjustment), Dust Proof Engine, 24/7 Hours Operating, Large H/V Lens Shift, Corner fit/ 2D keystone/ Digital shrink and shift, Blanking, Dynamic Dimming, Native Resolution Switch between 1080p and WUXGA, Fast mode to 16 ms latency, White balance calibration
  Connectivity
  HDMI	HDMI (HDCP 2.2) x2; HDMI out x1
  PC (D-sub 15pin)	x1
  Monitor out (D-sub 15pin,Female)	x1
  Audio in(mini jack)	x1
  Audio out (mini jack)	x1
  RS232 In (D-sub 9pin, male)	x1
  USB TypeA-2 (5V,1.5A)	x1
  USB Type mini B	x1 (FW download/ service)
  IR Receiver(Front+Top)	x2 (Front +Rear)
  LAN Port(RJ45 for Network )	x1
  Compatibility
  Resolution Support	VGA(640 x 480) to 4K UHD (3840 x 2160)
  Horizontal Frequency	15~135KHz
  Vertical Scan Rate	23 ~ 120 Hz
  HDTV Compatibility	480i, 480p, 576i, 567p, 720p, 1080i, 1080p
  Video Compatibility	NTSC, PAL, SECAM‎
  Power
  Power Consumption (Max/Normal/Eco)	500W/450W/350W
  Standby Power Consumption	Normal < 0.5Watts. Network < 2W.
  Power Supply	100 ~ 240V AC
  Dimension and Weight
  Product Dimensions (WxHxD)	479.6 x 182.8 x 402 mm
  Product Weight	12 kg
  Operation Condition
  Noise Level(Normal/Eco)	37/35dBA
  Operating Temperature	0 ~ 40°C
  Accessories
  Accessories (Standard)	Installation Guide, Safety Guide, Remote Control (RCA024), AA Batteryx2, Power Cord, Warranty card (by Region)
  Accessories (Optional)	Ceiling Mount (CMG6), 3D glasses
  OSD/Launcher	On Screen Display /Launcher Language
  Notes	Product Security Updates: LU960ST Guaranteed Product security updates until 12.31.2024
