Belkin Universal 2nd Gen Secure KVM Switch, 8-Port Dual Head w/ CAC | F1DN208KVM-UN-4
- Description
- Specifications
-
Belkin Universal 2nd Gen Secure KVM Switch, 8-Port Dual Head w/ CAC | F1DN208KVM-UN-4
Designed for NIAP Protection Profile PSD 4.0 Compliance
Combo connector video support for up to 4K (3840×2160), @60hz refresh
Compatible with the Belkin Secure KVM Remote Control with Integrated Keyboard (Optional)
Customizable port coloring and naming on the front panel: Facilitates port identification and reduces user switching errors. Color coding mimicked by Belkin KVM Remote Control with Integrated Keyboard
Extrusion form factor that supports an under-counter mount (Optional)
Supports TAA combo and video cables for easy deployment
Supports up to eight host computers
Supports two displays for the user
CAC and Audio freeze functionality
Dedicated processors with emulators for every port: Isolated port paths for video, audio, and peripherals prevent data leaks between computers
Unidirectional data paths: Optical data diodes prevent peripherals from being used to breach systems
Display security: Protected display interface prevents data leakage via the monitor
Analog audio via 3.5mm jack with ultrasonic audio filtering
Peripheral management: USB device detection prevents unauthorized peripheral usage
Active Anti-tampering and Secure labeling: Holographic tamper-evident product label provides visual indication and prevention of tampering
Fast switching: No keyboard or mouse delays when switching ports, minimal video delay
Secure packaging: Tamper-evident packaging ensures product is not tampered with during transport -
Attribute Details Ports CaC/DPP, Computers, Keyboard, Monitors, Mouse, Remote Security Features Designed for NIAP PP 4.0 Compliance Storage Temperature -4 to 140°F AC Plug Style Worldwide Power Cord with Interchangeable Mains Connector Certifications FCC Class A, UL, CE, RoHS, ICES, RCM Console Ports 1, Dual Monitors Display Connection DP/HDMI Display Type DP/HDMI Form Factor Desktop – Rack Mount Host Ports 8 Housing Type Formed Sheet Steel Indicator Light Status Port Selected, EDID, Keyboard, Mouse Keyboard Input 1 – USB Keyboard/Mouse Connections 2 – USB Keyboard Type USB KVM Maximum Resolution Supported 4K@60Hz Local Console Interfaces 1, Dual Monitors Maximum Resolution 4K@60Hz Mouse Input 1 – USB Mouse Type USB PC Ports 8 Power Rating 12VDC 4.0A Power Supply Included Yes Power Supply Type Internal Remote Control Included No Supported Audio Formats Analog via 3.5mm Supported Video Formats DP/HDMI TAA Compliant Yes Input Voltage (AC) 100-240 AC Plug Style IEC Female
