B-Tech System X Horizontal Mounting Rail 2m Silver | BT8390-200/S

• Description
• Specifications
• Downloads

• B-Tech System X Horizontal Mounting Rail 2m Silver


  System X Horizontal Mounting Rail, 2 m, Silver
  BT8390 horizontal mounting rails are the central component of any System X installation, whether it be for a complex multi-screen install or a single screen application. Made from aluminium, the rail itself is sturdy yet lightweight and is designed to support a variety of interface arms and mounts, allowing screens and other AV equipment to be fitted to the rail. Available in a range of lengths, the BT8390 can be mounted onto walls, poles or System X support columns using a range of different fixing kits (available separately). Rails can be cut to shorter lengths as required or joined together using extension kits (also available separately) for much longer installs.

• Feature	Details
  Housing Material	Aluminium
  Product Colour	Silver
  Product Type	Rail
  EU ECCN Code	N/A
  UNSPSC Code	45111809
  US ECCN Code	EAR99
  Package Dimensions
  – Depth	205.6 cm
  – Gross Weight	8.5 kg
  – Height	11 cm
  – Width	19.3 cm
  Packaging Content
  – Quantity per Pack	1 pc
  Product Dimensions
  – Net Weight	8.2 kg
  – Depth	3 cm
  – Height	12 cm
  – Width	200 cm
  Vendor Information
  – Brand Name	B-Tech
  – Homepage	B-Tech
  Categories	ProAV Solutions, Mounts & Furniture, Accessories, Monitor Mount Accessories

• Description	Downloads
  B-Tech System X Horizontal Mounting Rail 2m Silver | BT8390-200/S DataSheet	Downloads
  B-Tech System X Horizontal Mounting Rail 2m Silver | BT8390-200/S Assembly Leaflet	Downloads
  B-Tech System X Horizontal Mounting Rail 2m Silver | BT8390-200/S Drawing	Downloads
