B-Tech BT8428-100/B 32 to 65 inch Universal Flat Screen Ceiling Mount

• Description
• Specifications
• Warranty

• B-Tech BT8428-100/B 32 to 65 inch Universal Flat Screen Ceiling Mount


  Designed to ceiling mount two screens in a back-to-back configuration, the BT8428 is available in a choice of FIVE different drop lengths; 1m, 1.5m, 2m and 3m. The mount uses B-Tech’s unique ‘Torsion-Tilt’ mechanism for easy tilt up to +/-15°. Levelling screws are included on the interface arms to finely adjust the screen height and locking screws help prevent unauthorised removal of the screen

  Mounts two screens back-to-back
  Ceiling bracket can be tilted for mounting on angled ceilings
  Unique ‘Torsion-tilt’ mechanism for tool-less screen tilt adjustment
  Suitable for landscape or portrait mounting
  Lateral adjustment of screen once mounted
  Arms feature levelling screws to adjust the screen height
  Security screws help prevent unauthorised removal of screens
  Poles are supplied with safety bolt and grub screws for a secure installation
  Integrated cable management
  Simple ‘hook-on’ installation with all mounting hardware included

• Specification	Value
  Recommended screen size	up to 65″
  Max load	50kg per screen
  VESA® & non-VESA fixings	up to 468 x 400mm
  VESA® compatibility (with included adaptors)	up to 600 x 400
  Ceiling drop	460mm, 960mm, 1460mm, 1960mm, 2960mm*
  Tilt (at screen)	up to +/-15°
  Tilt (at ceiling)	up to +90°
  Colour option (050mm pole)	Black, White or Chrome

• BTECH AV MOUNTS
  5 Years Manufacturer Warranty
