Axis T8120 PoE Injector – 120 V AC, 230 V AC Input – 1 x 10/100/1000Base-T Input Port(s) | 5026-222

• Description
• Specifications

• Axis T8120 PoE Injector – 120 V AC, 230 V AC Input – 1 x 10/100/1000Base-T Input Port(s) | 5026-222

  Power over Ethernet (PoE) offers an easy, fast and cost-effective solution for powering network products. A midspan injects power and data to the network device with built-in PoE support. No need to replace existing Ethernet switches and cabling infrastructure. AXIS T8120 Midspan 15 W 1-port is a compact and flexible solution for your PoE-based network devices. AXIS T8120 delivers up to 15.4 W and it is IEEE 802.3af compliant and, which ensures compatibility with most of Axis network products that have built-in support for PoE.

• Category	Feature	Specification
  Compatibility	Axis Products	M1025, M1054, M1103, M1104, M1113, M1113-E, M1114, M1114-E, M1114-L, M1124, M1124-E, M1125, M1125-E, M1144-L, M1145, P1311, P1343, P1343-E, P1344, P1344-E, P1346, P1346-E, P1347, P1347-E, P1353, P1353-E, P1354, P1354-E, P1355, P1355-E, P1357, P1357-E, P1364, P1364-E, P1365, P1365-E, P1367, P1367-E, P1368-E, Q1602, Q1602-E, Q1604, Q1604-E, Q1614, Q1614-E, Q1615, Q1615-E, Q1635, Q1635-E, M2014-E, M2026-LE, P1405-E, P1405-LE, P1425-E, P1425-LE
  Certifications & Standards	Compliance	IEEE 802.3, IEEE 802.3af, cUL/UL, TUV, CE EN 62368-1, FCC Part 15 Class B, EN 55022, RMC AS/NZS CISPR 22 Class B, KCC KN32 Class A, KN35, IS 13252
  Environmental	Environmentally Friendly	Yes
  Input Ports	Port 1	1 x 10/100/1000Base-T
  	Port 2	1 x 10/100/1000Base-T
  Output Ports	Port 1	1 x 10/100/1000Base-T
  	Port 2	1 x 10/100/1000Base-T
  Physical	Weight (Approximate)	450 g
  	Mount Type	Wall/Shelf/DIN Rail-mountable
  	Height	53 mm
  	Width	33 mm
  	Depth	140 mm
  Product Details	Type	PoE Injector
  	Manufacturer Part Number	5026-222
  	Manufacturer	Axis Communications
  	Model	T8120
  	Name	T8120 Midspan 15 W 1-port
  	Brand Name	AXIS
  Power	Input Voltage	120 V AC, 230 V AC
  	Frequency Range	47 – 63 Hz
  	Max Input Current	500 mA
  	Max Output Power	15 W
  	Min Output Voltage	48 V DC
