• Axis Q6135-LE High-Speed  PTZ Network Camera With Long-Range OptimizedIR

  AXIS Q6135-LE is a high-speed PTZ camera that offers OptimizedIR up to 250 m (820 ft) as well as Lightfinder 2.0 for clear, sharp overviews and excellent details in demanding light conditions. It’s ideal for city surveillance in any unlit or low-light area – such as parks and alleys– eliminating the need for additional lighting.

  See it all – anytime, anywhere
  AXIS Q6135-LE is equipped with OptimizedIR with automatically adaptable IR LED illumination enabling surveillance in total darkness up to 250 m (820 ft) or more depending on the scene. Thanks to the sharpdome design it allows you to see 20° above the horizon with the same sharp image quality as below. It offers 32x optical zoom, superior video and excellent details in HDTV 1080p resolution. Featuring Lightfinder 2.0 this camera captures low-light images with more saturated colors and sharper images of moving objects. Furthermore, speed dry ensures clarity in rainy weather and supports efficient cleaning.


  Whenever, wherever it’s needed
  This top-of-the-line camera contains all the functionality you need to track and identify suspect behavior. With AXIS Object Analytics, it allows you to detect and classify humans and vehicles, all tailored to your specific needs. It includes orientation aid with support for dynamic overlays for quick orientation. Autotracking 2 with click and track functionality allows for active object tracking. Furthermore, where privacy must be kept, privacy masking with mosaic lets you pixelate whole areas such as a neighboring property. Additionally, Zipstream with support for H.264 and H.265 significantly lowers bandwidth and storage requirements without compromising image quality.


  Keeping you secure
  Thanks to the newest generation of Axis chip, AXIS Q6135-LE is packed with advanced security features to prevent unauthorized access and safeguard your system. Signed firmware and secure boot guarantee that the firmware hasn’t been compromised and ensure only authorized firmware is installed. And, if needed, secure boot guarantees the camera is completely free of malware after a factory default. For added peace of mind, it includes a Trusted Platform Module (TPM) that is FIPS 140-2 level 2 certified. This module ensures secure storage of all cryptographic keys and certificates even in the event of a security breach.

• Category	Property description	Property value
  Camera	Lightfinder	Lightfinder 2.0
  	Min illumination/ light sensitivity (Color)	0.06 lux
  	Min illumination/ light sensitivity (B/W)	0.008 lux
  	Image sensor	CMOS
  	Image sensor size	1/2.8″
  	Wide dynamic range	Forensic WDR
  General	Built-in IR	Yes
  	OptimizedIR	Yes
  	Local storage (memory card slot)	Yes
  	Operating temperature	-50 to 50 °C
  	Outdoor Ready	Yes
  	Vandal rating	IK08
  	IP rating	IP66
  	Designed for repaint	Yes
  Analytics	Autotracking version	Autotracking 2
  	Orientation aid	orientation aid PTZ
  Video	Max video resolution	1920×1080
  	Max frames per second	50/60
  	Day and Night functionality	Yes
  	Electronic image stabilization	Yes
  Lens	Focal length	4.3 – 137.6 mm
  	Horizontal field of view	58.3-2.4 °
  	Vertical field of view	34.9-1.3 °
  Pan, Tilt, Zoom	Optical zoom	32
  	Pan range	360 endless
  	Tilt range	+20 to -90
  	Guard tour	preset position tour
  	Digital zoom	12
  Compression	Zipstream	Yes
  	H.264	Baseline, High, Main
  	H.265	Yes
  	Motion JPEG	Yes
  Audio	Audio Support	Yes
  	Built-in microphone	–
  System Integration	Audio detection	–
  	Active tampering	–
  	Alarm inputs/outputs	–
  Network	PoE Class	High PoE
  Security	Signed OS	Yes
  	Secure boot	Yes
  	TPM	Yes
