Axis Q1656-LE Outstanding Performance in 4 MP Box Camera

• Description
• Specifications
• Downloads

• Axis Q1656-LE Outstanding Performance in 4 MP Box Camera

  With premium Q-line functionality and exceptional video quality even in poor light, AXIS Q1656-LE is based on the latest Axis system-on-chip (SoC) and offers support for powerful analytics based on deep learning on the edge.

  The best of the best
  AXIS Q1656-LE delivers exceptional video quality even in poor light conditions. This premium Q-line camera offers impressive performance with 4 MP resolution at up to 60 fps. With a 1/1.8” sensor, it provides the best possible image quality no matter what. Plus, a built-in wiper guarantees great images even in snow and rain. It includes Lightfinder 2.0 to capture outstanding forensic images in low light scenes. And, the built-in camera rails allow you to easily adjust or change the lens to a larger tele lens or i-CS lens. Furthermore, it includes a power-efficient IR White LED illumination.


  Powerful analytics capabilities
  This high-performance camera is based on ARTPEC-8, the latest Axis system-on-chip (SoC). Featuring a deep learning processing unit (DLPU), it eliminates the need for expensive servers and allows for a faster and more scalable system. Plus, it improves processing capabilities so you can collect and analyze even more data than before – on the edge. AXIS Object Analytics offers detection and classification of humans, vehicles, and types of vehicles—all tailored to your specific needs. Furthermore, with support for ACAP version 4, you can add value to your system with tailor-made applications based on deep learning on the edge available from Axis and our partners.


  Reliable and secure
  Designed for easy and reliable installation, AXIS Q1656-LE is enclosed in a robust, impact-resistant IK10-rated casing. With IP66, IP67, NEMA 4X, and NEMA TS2 ratings, this water-resistant, weatherproof camera can also withstand winds up to 60 m/s. Including remote zoom and focus and support for PoE and redundant DC power, it offers flexible installation and maintenance. Plus, your data is safeguarded in the event of a power outage. It also includes surge protection (railway standard) and an intrusion switch for secure operation. Furthermore, built-in cybersecurity features prevent unauthorized access and safeguard your system.

• Category	Property Description	Property Value
  Image Sensor	Image sensor	CMOS
  	Image sensor size	1/1.8″
  	Lightfinder	Lightfinder 2.0
  	Wide dynamic range	Forensic WDR
  	Min illumination/light sensitivity (Color)	0.05 lux
  	Min illumination/light sensitivity (B/W)	0.01 lux
  Video	Max video resolution	2688×1512
  	Max frames per second	50/60
  	Electronic image stabilization	Yes
  Lens	Focal length	3.9 – 10 mm
  	Horizontal field of view	113-47 °
  	Vertical field of view	60-27 °
  	Lens mount	CS
  	Replaceable lens	Yes
  Compression	Zipstream	Yes
  	H.264	Baseline, High, Main
  	H.265	Yes
  	Motion JPEG	Yes
  Audio	Audio Support	Yes
  Network	PoE Class	4
  	Wireless	–
  Security	Signed OS	Yes
  	Secure boot	Yes
  General	Remote focus	Yes
  	Remote zoom	Yes
  	Built-in IR	Yes
  	Local storage (memory card slot)	Yes
  	Operating temperature	-40 to 60 °C
  	Outdoor Ready	Yes
  	Vandal rating	IK10 Except for front window IK08
  	IP rating	IP66, IP67
  	Designed for repaint	Yes
  	Sustainability	BFR/CFR free, PVC free
  Power	Power (max)	25.5 W
  	Power (average)	11.2 W
  	DC input voltage	10-28 V
