Axis PoE Injector – 24 V AC Input – 56 V DC Output – Gigabit Ethernet Input Port(s) | 02208-001

• Description
• Specifications

• Axis PoE Injector – 24 V AC Input – 56 V DC Output – Gigabit Ethernet Input Port(s) | 02208-001

  AXIS 30 W Midspan AC/DC is ideal for installations where mains power is not an option. With a power input of either 10-28 V DC or 24 V AC, it can deliver up to IEEE 802.3at (30 W) to your network device. AXIS 30 W Midspan AC/DC is plug-and-play and compatible with all Axis PoE devices which require up to 30 W power.

  24 V AC can be needed in harsh environments where new cabling or installations are not possible and you need to retrofit box, dome or PTZ cameras.

  10-28 V DC can be used where battery back-up is needed or for solar-powered installations. Or when the network device is built in another equipment and is powered directly from it, for example, in an ATM.

• Category	Feature	Specification
  Input Ports	Port 1	Gigabit Ethernet
  	Port 2	Gigabit Ethernet
  Output Ports	Type	PoE
  Additional Information	DC Input Voltage	10 to 28V DC
  	AC Input Voltage	24 ±20% VAC
  	Connectors	Shielded RJ45, EIA568A & 568B, 3-pin AC/DC connector
  	Sustainability	PVC-free, Halogen-free
  	Display and Indicators	PoE LED
  Compatibility	Type	Network Device
  Certifications & Standards	Compliance	IEEE 802.3af, IEEE 802.3at
  	Safety	IS 13252, IEC/EN/UL 62368-1
  	Environmental Standards	IEC 60068 series
  	EMC	EN 55024, EN 55032 Class A, FCC Part 15 Subpart B Class A, CISPR 32 Class A, VCCI Class A, KC KN32/35, RCMAS/NZS, EAC
  Environmental	Environmentally Friendly	Yes
  Power	Input Voltage	24 V AC
  	Max Output Power	30 W
  	Max Output Voltage	56 V DC
  Product Details	Type	PoE Injector
  	Manufacturer Part Number	02208001
  	Manufacturer	Axis Communications
  	Model	30 W Midspan AC/DC
  	Brand Name	AXIS
  Physical	Weight	233 g
  	Mount Type	Wall/Shelf/DIN Rail-mountable
  	Height	164 mm
  	Width	65 mm
  	Depth	37 mm
  	Color	Black
