AVer VC520 Pro Teams Edition 1080P 12x Zoom USB Camera and Speaker Microphone Kit

• Description
• Specifications
• Downloads

• AVer VC520 Pro 1080P 12x Zoom USB Camera and Speaker Microphone Kit

  Professional conferencing system for mid-to-large rooms
  The VC520 Pro is equipped with a 12X optical zoom and daisy-chain speakerphone that deliver a lifelike audiovisual experience. With 1080p HD quality, Sony True WDR, and IP-based management features, the VC520 Pro is the professional conferencing system your enterprise needs.

  VC520 Pro Microsoft Teams Rooms Edition
  This exclusive version of the VC520 Pro speakerphone lets you start meetings instantly with an embedded Microsoft Teams button* and LED status indicator. Just touch the button to enter a meeting and check the call status. Also, you can enjoy an always-clear audio experience via the two expansion microphones that come with this special edition system.
  * Only available for the VC520 Pro Microsoft Teams Rooms edition, which includes a camera, a speakerphone, and two expansion microphones.

  Perfect Audio for Professional Conferencing
  Experience lifelike audio in various sizes of meeting rooms with the VC520 Pro. The speakerphone’s pickup range is up to 6 meters in diameter, or you can daisy-chain two additional speakerphones to fit into your conference room configuration. Touch controls make it easy to adjust or mute the volume, and echo cancellation ensures a steady audio experience. You can also connect extra microphones for ultra-clear voice pickup.

  Daisy-Chain Speakphone

  Full Duplex Microphone Array

  Configuration

  SmartFrame Captures Everyone in Seconds
  Improve productivity by starting meetings instantly. The VC520 Pro processes facial recognition to capture everyone on-screen in seconds and automatically re-frames whenever someone walks in or out of the room.

  Professional Clarity with an 18X Total Zoom
  Show every detail precisely and smoothly to enhance communication. The VC520 Pro is embedded with a 12X true optical zoom and multi-coated auto-focus optics to present complex product details in full HD 1080p quality.

  Hold Meetings Anywhere with True WDR
  Maintain constant clarity in high-contrast backlight environments. The VC520 Pro’s embedded Sony sensor provides True WDR up to 120dB, controling the exposure and light values of pixels in any lighting.

  Video Streaming and Remote Control via IP-Based Management
  The VC520 Pro features advanced centralized management through the Chrome browser. Remotely control the camera and share on Facebook or YouTube with H.264 and AAC-LC RTSP/RTMP streaming in 1080p at 60fps via USB 3.1.

  Hardware Spec

  Camera

  Speakerphone


• Category	Details
  Camera
  Sensor	Sony super-low-light 2M pixel sensor
  Resolution	See list in specs (16:9 and 4:3 aspect ratios)
  Zoom	18X total zoom (12X optical zoom)
  Field of View (DFOV)	82°
  Lens Focal Length	3.9 mm (wide) to 47.3 mm (tele)
  Lens F#	1.8 (wide) to 2.8 (tele)
  Pan & Tilt Movement	Pan: ±170°, Tilt: +90° (up) -30° (down)
  Presets	10 presets (remote control)
  Video Format	YUV, MJPEG, H.264
  Network Video Compression	H.264
  Network Protocols	RTSP, RTMP
  Speakerphone
  Microphone Array	Full duplex with echo cancellation, Advanced noise suppression
  Dual-Microphone Array	Yes
  Phone-in/Line-out Jacks	3.5 mm
  Speaker Output	6W, Adjustable to 90dB SPL at 0.5 m
  Microphone Frequency Response	120Hz–16kHz
  Microphone Sensitivity	-34± 2 dBV @1KHz, 94dBSPL
  Touch Controls	Volume down/up, mute, phone input, call, hang-up, bridge phone-in and USB into one call
  LAN
  Speed	10/100/1000 Mbps
  Security	Kensington slot
  Audio Format	AAC-LC
