AVer TR335N 4K 30X Optical Zoom AI Auto Tracking NDI®|HX PTZ Camera

• Description
• Specifications
• Downloads

• AVer TR335N 4K 30X Optical Zoom AI Auto Tracking NDI®|HX PTZ Camera

  AI Auto Tracking NDI®|HX PTZ Camera
  Equipped with NDI®|HX3 capability, AVer’s new TR335N AI Auto Tracking PTZ Camera extends powerful and dependable Pro AV prowess to users across the spectrum of industries. The TR335N showcases proprietary functions — including Presenter Mode, Zone Mode, and Hybrid Mode tracking — driven by advanced AI processing. Seamlessly blending a 30X Optical Zoom lens, 4K 60 fps resolution, and the finesse of hybrid auto tracking and smooth PTZ operations, it’s already the quintessential choice for broadcasting, streaming, or recording.


  NDI® is a registered trademark of Vizrt NDI AB.
  NDI® is in the hands of millions of users allowing multiple video systems to identify and communicate with one another over IP. NDI® can encode, transmit and receive many streams of high quality, low latency, frame-accurate video and audio in real time. This benefits any network-connected video device, including video mixers, graphics systems, capture cards, and many other production devices. This makes it possible to exponentially increase the number of sources available for live production switching, without directly attaching to devices, changing locations, or investing in expensive, high-bandwidth networks that simply replace SDI-based workflows.


  NDI® HX3 Levels Up Streaming
  Elevate your streaming experience with the TR335N’s cutting-edge NDI® HX3 technology! Revel in lossless, low-latency video streaming without complex configurations. This innovation is reshaping the landscape of contemporary video content sharing and production.

  30X Optical Zoom Magnifies Details
  Experience the exceptional power of the TR335N camera’s astounding 30X optical zoom. This feature seamlessly operates even while the camera is panning and tilting, granting you the ability to accentuate content and quickly shift between shooting perspectives. Embrace the advantage of dynamic, crystal-clear video feeds through the TR335N’s unparalleled PTZ performance.


  HDMI/USB/IP. 4K 60 FPS.
  Leverage the TR335N’s 4K 60 fps streaming potential through HDMI, USB, and IP outputs. Free from intricate configurations and cable entanglements, you can effortlessly use multiple devices simultaneously to produce fluid video streams.


  Presenter Mode
  Get unparalleled tracking performance with Presenter Mode. This dynamic feature empowers presenters to venture beyond the stage to engage with their audience while the camera maintains seamless tracking.


  Zone Mode
  Zone Mode elevates your ability to capture content across multiple displays. Generate up to four dedicated Content Zones to consistently capture displayed information or items, prioritizing important presentation materials over the presenter’s movements.


  Hybrid Mode
  Free your performers by enabling unrestricted movement with Hybrid Mode. Use preset areas for zone tracking, letting the camera seamlessly switch to a full view of each pre-defined location as performers move through the areas. If they move beyond these zones, the camera seamlessly adapts, switching to presenter mode to effortlessly and precisely track their movements.


  Hardware Specifications
  Front

  1. Tally Lamp
  2. IR Sensor
  3. LED Indicator

  Back

  1. PoE+
  2. RS-232
  3. RS-422
  4. USB 3.1 Type-B
  5. Line In
  6. HDMI
  7. 3G-SDI
  8. DC 12V

• Category	Specification
  Camera
  Image Sensor	1/2.8” 4K Exmor CMOS
  Effective Picture Elements	8 Megapixels
  Output Resolutions	4K/60, 4K/59.94, 4K/50, 4K/30, 4K/29.97, 4K/25, 1080p/60, 1080p/59.94, 1080p/50, 1080p/30, 1080p/29.97, 1080p/25, 1080i/60, 1080i/59.94, 1080i/50, 720p/60, 720p/59.94, 720p/50
  Minimum Illumination	0.5 lux (IRE50, F1.6, 30fps)
  S/N Ratio	≥ 50 dB
  Gain	Auto, Manual
  TV Lines	1600 (Center)
  Shutter Speed	1/1 to 1/32,000 sec
  Exposure Control	Auto, Manual, Priority AE (Shutter, IRIS), BLC, WDR
  White Balance	Auto, Manual
  Optical Zoom	30X
  Digital Zoom	12X
  Viewing Angles	DFOV : 69.2° (Wide) to 2.8° (Tele); HFOV : 62.3° (Wide) to 2.5° (Tele); VFOV : 37.3° (Wide) to 1.4° (Tele)
  Focal Length	f = 4.5 mm (Wide) to 135 mm (Tele)
  Aperture (Iris)	F = 1.8 (Wide) to 4.7 (Tele)
  Minimum Working Distance	0.1 m (Wide); 1.2 m (Tele)
  Pan / Tilt Angles	Pan : ±170°; Tilt : +90° / -30°
  Pan / Tilt Speed (Manual)	Pan : 0.1° to 100° / sec; Tilt : 0.1° to 100° / sec
  Preset Speed	Pan : 200° / sec; Tilt : 200° / sec
  Preset Positions	10 (IR); 256 (RS-232, RS-422, IP)
  Camera Control – Interfaces	RS-232 (DIN8); RS-422 (RJ45); IP; USB
  Camera Control – Protocols	VISCA (RS-232 / RS-422 / IP); PELCO-D & PELCO-P (RS-232 / RS-422); CGI (IP); ONVIF
  Image Processing	Noise Reduction (2D / 3D); Flip; Mirror; WDR; BLC
  Power Frequencies	50 Hz, 60 Hz
  AI Auto Tracking Functions
  Tracking Modes	Presenter Mode; Zone Mode; Hybrid Mode
  Privacy Protection Mechanisms	Protection Mode; Sleep Mode
  AI Control Functions	Gesture Control: Yes
  Audio
  Channels	2ch Stereo
  Codecs	AAC-LC (48K); PCM (8K)
  Sample Rates	48 / 44.1 / 32 / 24 / 16 / 8 KHz
  Interface
  Video Outputs	3G-SDI, HDMI, IP, USB
  Audio Outputs	3G-SDI, HDMI, IP, USB
  Audio Inputs	MIC in, Line in
  General
  Power Requirement	AC 100 – 240V to DC 12V/5A
  Power Consumption	19W
  PoE	PoE+
  Dimensions (W x H x D)	180.0 x 192.0 x 145.0 mm
  Net Weight	2.0 (±0.1) kg
  Application	Indoor
  Tally Lamp	Yes
  Security	Kensington Slot
  Remote Control	Infrared
  Operating Conditions	Temperature : 0 °C to +40 °C; Humidity : 20% to 80%
  Storage Conditions	Temperature : -20 °C to +60 °C; Humidity: 20% to 95%
  IP Streaming
  Resolution	2160p 60fps
  Network Video Compress Formats	H.264, H.265, MJPEG
  Network Audio Compress Formats	AAC-LC (48K), PCM (8K)
  Maximum Frame Rate	2160p 60fps
  Bit-Rate Control Modes	VBR, CBR (selectable)
  Range of Bit-Rate Setting	512 Kbps to 32 Mbps
  Network Interface	10 / 100 / 1000 Base-T
  Multi-Stream Capability**	4
  Network Protocols	IPv4, TCP, UDP, ARP, ICMP, IGMP, HTTP, HTTPS, DHCP, RTP / RTCP, RTSP, RTMP, SRT, HLS, NDI, LLDP, VISCA over IP
  NDI® HX3	Yes
  USB
  Connector	USB 3.1
  Video Formats	MJPEG, YUY2
  Audio Format	PCM
  Maximum Video Resolution	2160p
  USB Video Class (UVC)	UVC 1.1
  USB Audio Class (UAC)	UAC 1.0
  Web UI
  Live Video Preview	Yes
  Camera PTZ Control	Pan, Tilt, Zoom, Focus, Preset Control
  Camera / Image Adjustment	Exposure, White Balance, Picture
  Network Configuration	DHCP, IP Address, Gateway, Subnet Mask, DNS
  Software Tools	IP Search and Configuration Tool
  Support Windows® 7 or later	Yes
  PTZ Management	Support Windows® 7 or later
  PTZ Control Panel	Supports iOS & iPadOS® 11 or later
  PTZ Link	Supports Windows® 7 or later, macOS® 10.14 or later
  OBS Plugin for PTZ Cameras	Supports Windows® 8 or later, macOS® High Sierra v10.13 or later
  CaptureShare	Supports Windows® 7 or later, macOS® 10.14 or later
  Warranty
  Camera	5 Years
  Accessories	1 Year
  Package Contents
  Camera	Yes
  Remote Control	Yes
  RS-232 In/Out Cable	Yes
  Din 8 To D-Sub 9 Cable	Yes
  Power Adapter	Yes
  Power Cord	Yes
  Cable Ties (x 4)	Yes
  M2 x 4 mm Screws (x 3)	Yes
  M3 x 6 mm Screws (x3)	Yes
  1/4′-20L 6.5mm Screws (x2)	Yes
  Cable Fixing Plate	Yes
  Ceiling Mount Brackets (x 2)	Yes
  Drilling Paper	Yes
  Quick Start Guide	Yes
  Optional Accessories
  AVer CL01 PTZ Camera Controller	Yes
  L-Type Wall Mount	Yes
