AVer PTZ310 1080P 12X Zoom Camera Capture Events in Lifelike Quality

• Description
• Specifications
• Downloads

• AVer PTZ310 1080P 12X Zoom Camera Capture Events in Lifelike Quality


  Professional PTZ Camera
  AVer PTZ310 is available in white or grey and equipped versatile functions to suite every classroom, hospital, or business. Creating the superior video quality, the PTZ310 makes you feel the action in a scene!

  12X Optical Zoom
  Resounding image quality and a 12X optical zoom enable you to capture crystal-clear footage in any classroom, hall, or activity center.

  Full HD Resolution
  The PTZ310 provides outstanding image quality in full HD 1080p at 60fps. It also offers the best auto focus, auto exposure, and auto white balance performance.

  Up to 255 Preset Locations
  Always be prepared to capture every angle and change the recording view at a moment’s notice with up to 255 preset locations through VISCA via RS232 and RS422 functionality, and 10 preset locations through IR remote control.

  Stable Motion Control
  Fully optimize your recording with customizable speed settings from 0.1°to 200° per second that maximize the agility and precision of pan/tilt rotation motion control.

  Seamless Tracking Between Your Preset Zones
  AVer SmartShoot optimizes your camera controls for automatic and seamless content capturing between your preset areas. With SmartShoot’s preset zone tracking you can create an uncompromising multi-camera feel with just one PTZ310 across all your preset zones. Save effortand time, while providing your video with a huge variety of shooting ranges.

  Fit Your FOV in Seconds
  AVer’s new SmartFrame provides you with one-touch face targeting technology to create stunning video content fast. SmartFrame instantly adjusts your FOV to fit everyone on screen at stunning speed so you can start recording presentations, lectures, and more with no hassle. Perfect for capturing multiple people, SmartFrame makes video content capturing easy and enjoyable.

• Specifications	Details
  Camera
  Image sensor	1/2.8″ 1080p 60fps Exmor CMOS
  Effective Picture Elements	Approx. 2.1 megapixels
  Output Resolution	Auto, 1080p@60, [email protected], 1080p@50, …
  Minimum Illumination	0.4 lux (IRE50, F1.6, 30fps)
  S/N Ratio	> 50dB
  Gain	Auto / Manual
  TV Line	800 (Center/Wide), 700 (Corner/Wide)
  Shutter Speed	1/1s – 1/32,000s
  Exposure Control	Auto, Manual, Priority AE (Shutter, IRIS), BLC
  White Balance	Auto / Indoor / Outdoor / One-push / Manual
  Optical Zoom	12X
  Digital Zoom	12X
  Horizontal Viewing Angle	72.5° (Wide) – 6.3° (Tele)
  Focal length	f = 3.9 mm (Wide) – 46.8 mm (Tele)
  Aperture (Iris)	F = 1.6 (Wide) – 2.8 (Tele)
  Minimum Working Distance	0.3 m (Wide), 1.5 m (Tele)
  Pan/Tilt Angle	Pan: +- 170° ; Tilt: +90°/-30°
  Pan/Tilt Speed (manual)	Pan: 0.1 – 100°/sec, Tilt: 0.1 – 100°/sec
  Preset Speed	Pan: 200° /sec, Tilt: 200° /sec
  Preset Position	10 (IR), 255 (RS-232)
  Camera Control – Interface	RS-232 (DIN9) / RS-422 (RJ45)
  Camera Control – Protocol	VISCA (RS-232/RS-422/IP), CGI (IP), PELCO-D, PELCO-P
  Image Processing	Noise Reduction (2/3D), Flip, Mirror
  Power Frequency	Auto / 50Hz / 60Hz
  Audio
  Channel	2ch (Stereo)
  Codec	AAC-LC (48/44.1/32/24K), G.711/PCM
  Sample Rate	48/44.1/32/24/16/8Khz
  Interface	Video Output, Audio Output, Audio Input
  General
  Power Requirement	AC100V-AC240V to DC12V/5A
  PoE	POE+ (IEEE 802.3at), Class 4
  Operating Condition	Temperature: 0°C – +40°C ; Humidity: 20% – 80%
  Storage Condition	Temperature: -20°C – +60°C ; Humidity: 20% – 95%
  Dimensions	L=180 mm, W= 145 mm, H= 183.5 mm
  Weight	1.74 kg
  Application	Indoor
  Security	Kensington slot
  Remote Control	Infrared
  Accessories	Remote control, 12V/5A power adapter
  IP Streaming
  Resolution	1920×1080, 1280×720, 960×540, 640×480
  Network Video Compress Format	H.264 (High Profile), MJPEG
  Maximum Frame Rate	H.264: 60fps (1920×1080), MJPEG: 30fps (1920×1080)
  Bit-rate Control Mode	VBR/CBR (selectable)
  Range of Bit-rate setting	512Kbps – 32Mbps
  Network Interface	10/100/1000Base-T
  Multi-stream Capability	2
  Network Protocol	IPv4, TCP, UDP, ARP, ICMP, IGMP, …
  USB
  Connector	Micro-USB 2.0
  Video Format	YUV, MJPEG, H.264
  Maximum Video Resolution	Up to 1080p
  USB Video Class	UVC1.1
  USB Audio Class	UAC1.0
  Web UI	Live Video Preview
  Camera PTZ Control	Pan / Tilt / Zoom / Focus / Preset Control
  Camera / Image Adjustment	Exposure / White Balance / Picture
  Network Configuration	DHCP, IP Address, Gateway, Subnet Mask, DNS
  Software Tools	Device IP Searching, Configuration Tool, Windows App
  Warranty	Camera: 3 Years**, Accessories: 1 Year
