APC SRT8KXLI Smart-UPS On-Line, 8kVA/8kW, Tower, 230V 3:1 and 1:1, 6x C13+4x C19 IEC Outlets

• Description
• Specifications
• Downloads

• APC SRT8KXLI Smart-UPS On-Line, 8kVA/8kW, Tower, 230V 3:1 and 1:1, 6x C13+4x C19 IEC Outlets

  This APC Smart-UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 8kVA on-line tower UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. It comes with hard wire 3-wire(1P+N+E)/5-wire(3P+N+E) input, 6x IEC 320 C13, 4x IEC 320 C19 outlets, and 3x IEC jumper cables. The UPS has an embedded Network Management Card for UPS network-based monitoring and management. The UPS comes with PowerChute Network Shutdown that provides graceful shutdown of physical servers, virtual machines, and HCI clusters. It has an additional SmartSlot for optional accessory card such as Dry Contact I/O card. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The UPS has a 3-year warranty, and the built-in lead-acid battery has a 2-year warranty. The UPS is compatible with SRTRK2 (4-post) and SRTRK3 (2-post) rail kits sold separately.

• Category	Description
  Main
  Run time for load	8000 W
  Min-max: 800-8000 W
  5min 14s
  Max. Capacity Used	100 %
  Main Input Voltage	230 V
  	400 V 3 phases
  Other Input Voltage	220 V
  	240 V
  	380 V
  	415 V
  Main Output Voltage	230 V
  Other Output Voltage	220 V
  	240 V
  Rated power in W	8000 W
  Rated power in VA	8000 VA
  Output connection type	6 IEC 60320 C13
  	3 IEC Jumpers
  	4 IEC 60320 C19
  Output connector type	Hard wire 3-wire (H N + E) 1
  Provided equipment	CD with software
  	Documentation CD
  	Installation guide
  	Temperature probe
  	USB cable
  	Warranty card
  	Web/SNMP management card
  Batteries & Runtime
  Run Time	View Runtime Graph
  Efficiency	View Efficiency Graph
  Battery type	Lead-acid battery
  Number of battery filled slots	0
  Battery recharge time	1.5 h
  Number of battery replacement qty	2
  Battery voltage	+/- 192 V (split battery referenced to neutral)
  Battery charger power	876 W rated
  Battery life	3…5 year(s)
  Replacement battery	APCRBC140
  Extended runtime	1
  General
  UPS type	Double conversion online
  Product web sub-family	High density
  Number of power module free slots	0
  Number of power module filled slots	0
  Redundant	No
  Physical
  Colour	Black
  Height	43.2 cm
  Width	26.3 cm
  Depth	71.5 cm
  Net weight	111.82 kg
  Mounting location	Front
  Mounting preference	No preference
  Mounting mode	Rack-mounted with kit
  	Two post mountable
  USB compatible	Yes
  Input
  Network frequency	40…70 Hz auto-sensing
  Number of input connectors	1 hard wire 3-wire (1P + N + E)
  	1 hard wire 5-wire (3P + N + E)
  Input voltage limits	100…275 V adjustable (half load)
  	173…476 V adjustable (half load)
  Output
  Maximum configurable power in VA	8000 VA
  Maximum configurable power in W	8000 W
  Output frequency	50/60 Hz +/- 3 Hz sync to mains
  Wave type	Sine wave
  Harmonic distortion	Less than 2 %
  Crest factor	3 : 1
  Bypass type	Internal bypass (automatic and manual)
  Conformance
  Product certifications	CE
  	EAC
  	IRAM
  	RCM
  	VDE
  Marking	CE Mark
  Standards	EN/IEC 62040-1:2019/A11:2021
  	EN/IEC 62040-2:2006/AC:2006
  	EN/IEC 62040-2:2018
  Environmental
  Ambient air temperature (operation)	0…40 °C
  Relative humidity	0…95 % non-condensing
  Operating altitude	0…10000 ft
  Ambient air temperature (storage)	-15…45 °C
  Storage Relative Humidity	0…95 % non-condensing
  Storage altitude	0.00…15240.00 m
  Acoustic level	55 dBA
  Heat dissipation	1497 Btu/h
  IP degree of protection	IP20
  Communications & Management
  Free slots	1
  Preinstalled device	Network management card 3 with environmental monitoring
  Alarm	Audible and visible alarms : prioritized by severity
  Emergency power off	Yes
  Surge Protection and Filtering
  Surge energy rate	480 J
  Packing Units
  Unit Type of Package 1	PCE
  Number of Units in Package 1	1
  Package 1 Height	46.1 cm
  Package 1 Width	60 cm
  Package 1 Length	100 cm
  Package 1 Weight	126.82 kg
  Logistical informations
  Country of origin	PH
  Contractual warranty	3 years repair or replace (excluding battery)
  	2 years for battery
