APC SMC1000IC Smart-UPS C, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 Outlets

• Description
• Specifications
• Downloads

• APC SMC1000IC Smart-UPS C, Line Interactive, 1000VA, Tower, 230V, 8x IEC C13 Outlets

  This APC Smart-UPS is designed for small to medium business owners to maintain business uptime and continuity. This 1000VA line interactive tower UPS provides pure sine wave power to support critical electronics during power disruptions. The UPS comes with IEC 320 C14 input and 8x IEC 320 C13 outlets. This UPS offers cloud-based remote power monitoring, UPS firmware upgrades, remote diagnostics and proactive email notifications with recommended actions. The Smart-UPS C has an intuitive graphic LCD interface. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. This line interactive UPS operates in green mode for high operating efficiency. The SMC has a 2-year warranty, and comes with a built-in lead-acid battery. This UPS provides surge protection against lightning strikes, power sags, brownouts and surges. This is compatible with a dedicated user-replaceable battery, and the APC replacement battery cartridge helps restore UPS performance to the original specifications. Designed for small offices or small business owners to maintain a core network and business communication.

• Main
  Run time for load	600 W
  	Min-max: 60-600 W
  	9min 22s
  Max. Capacity Used	100 %
  Main Input Voltage	230 V
  Other Input Voltage	220 V
  	240 V
  Main Output Voltage	230 V
  Other Output Voltage	220 V
  	240 V
  Rated power in W	600 W
  Rated power in VA	1000 VA
  Product or component type	Uninterruptible power supply (UPS)
  Input Connection Type	IEC 320 C14
  Output Connection Type	8 IEC 60320 C13
  Battery type	Lead-acid battery
  Provided Equipment	Power cord
  	USB cable
  Complementary	Software package
  	SmartConnect software for remote power monitoring feature availability varies by terms of use
  Batteries & Runtime
  Run Time	View Runtime Graph
  Efficiency	View Efficiency Graph
  Battery voltage	24 V
  Extended runtime	0
  Battery capacity	9 Ah
  Number of battery filled slots	0
  Number of battery free slots	0
  Battery recharge time	3 h
  Number of battery replacement quantity	1
  Battery life	3…5 year(s)
  Replacement battery	APCRBC142
  Battery charger power	56 W rated
  General
  Number of power module filled slots	0
  Number of power module free slots	0
  Product web sub-family	Cloud-enabled monitoring
  Redundant	No
  Physical
  Colour	Black
  Height	21.9 cm
  Width	17.1 cm
  Depth	43.9 cm
  Net weight	17.27 kg
  Mounting location	Front
  Mounting preference	No preference
  Mounting mode	Not rack-mountable
  	Two post mountable
  USB compatible	Yes
  Input
  Input voltage limits	170…300 V adjustable
  	180…287 V
  Network frequency	50/60 Hz +/- 3 Hz auto-sensing
  Output
  Harmonic distortion	Less than 5 %
  Maximum configurable power in VA	1000 VA
  Maximum configurable power in W	600 W
  Transfer time	6 ms typical : 10 ms maximum
  UPS type	Line interactive
  Wave type	Sine wave
  Output frequency	50/60 Hz +/- 3 Hz sync to mains
  Conformance
  Product certifications	CE, GOST, VDE
  Standards	EN/IEC 62040-1:2019/A11:2021, EN/IEC 62040-2:2006/AC:2006, EN/IEC 62040-2:2018
  Environmental
  Acoustic level	41 dBA
  Heat dissipation	100 Btu/h
  Operating altitude	0…10000 ft
  Ambient air temperature for operation	0…40 °C
  Ambient air temperature for storage	-15…45 °C
  Storage altitude	0.00…15240.00 m
  Relative humidity	0…95 %
  Storage Relative Humidity	0…95 %
  Communications & Management
  Control panel	Multifunction LCD status and control console
  Free slots	0
  Communication port support	SmartConnect Ethernet port: for cloud monitoring feature availability varies by terms of use
  Alarm	Alarm when on battery : distinctive low battery alarm : configurable delays
  Surge Protection and Filtering
  Surge energy rate	455 J
  Noise suppression	Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
  Packing Units
  Unit Type of Package 1	PCE
  Number of Units in Package 1	1
  Package 1 Height	37.6 cm
  Package 1 Width	59.5 cm
  Package 1 Length	32.8 cm
  Package 1 Weight	19.55 kg
  Logistical Information
  Country of origin	PH
  Contractual Warranty
  Warranty	2 years repair or replace

• Description	Downloads
  SMC1000IC:Datasheet	Download
  SMC1000IC:User Guide	Download
