APC BK650EI Back-UPS, 650VA, Tower, 230V, 4 IEC C13 Outlets , User Replaceable Battery

• Description
• Specifications
• Downloads

• APC BK650EI Back-UPS, 650VA, Tower, 230V, 4 IEC C13 Outlets , User Replaceable Battery

  This product is part of the Back-UPS range. The BK650EI features a total of 6 power outlets, 3 of which are UPS battery backup and 3 that are surge only. Its runtime at 100W is 35 minutes. It provides data line protection with a RJ45 analog phone line for phone or fax or modem or DSL. Its dimensions are 16.5 x 9.1 x 28.4 cm and 6.03 kg The BK650EI ensures office systems and their valuable data are protected from dangerous power surges, spikes and blackouts.

• Category	Description
  Main
  Run time for load	400 W
  Min-max power	40-400 W
  Max. Capacity Used	100%
  Main Input Voltage	230 V
  Main Output Voltage	230 V
  Rated power in W	400 W
  Rated power in VA	650 VA
  Product or component type	Uninterruptible power supply (UPS)
  Input Connection Type	IEC 60320 C14
  Output Connection Type	3 IEC 60320 C13, 1 IEC 60320 C13 surge, 2 IEC Jumpers surge
  Number of cables	2
  Battery type	Lead-acid battery
  Provided equipment	CD with software, Documentation CD, 2 x detachable IEC C13 to IEC C14 power cords, USB cable
  Batteries & Runtime
  Run Time	3min 35s
  Battery recharge time	8 h
  Number of battery replacement quantity	1
  Battery voltage	12 V
  Battery capacity	9.0 Ah
  Battery charger power	12 W rated
  Battery power in VAH	111 VAh capacity, 111 VAh runtime
  Battery life	4-6 year(s)
  Replacement battery	RBC17
  Physical
  Colour	Beige
  Height	16.5 cm
  Width	9.1 cm
  Depth	28.4 cm
  Net weight	6.03 kg
  Mounting location	Front
  Mounting mode	Not rack-mountable, Two post mountable
  USB compatible	Yes
  Input
  Network frequency	47-63 Hz
  Input voltage limits	160-286 V adjustable, 180-266 V
  Maximum input current	7 A
  Switching current capacity	7 A
  Output
  Maximum configurable power in W	400 W
  Output frequency	47-63 Hz sync to mains, 50/60 Hz +/- 1 Hz unsynchronised
  UPS type	Standby
  Wave type	Stepped approximation to a sinewave
  Maximum configurable power in VA	650 VA
  Transfer time	6 ms typical : 10 ms maximum
  Environmental
  Ambient air temperature for operation	0-40 °C
  Relative humidity	5-95 %
  Operating altitude	0-10000 ft
  Ambient air temperature for storage	-15-45 °C
  Storage Relative Humidity	5-95 %
  Storage altitude	0.00-15240.00 m
  Acoustic level	45 dBA
  Communications & Management
  Control panel	LED status display with on line, on battery, replace battery, and overload indicators
  Alarm	Alarm when on battery, distinctive low battery alarm, overload continuous tone alarm
  Surge Protection and Filtering
  Surge energy rate	310 J
  Packing Units
  Unit Type of Package 1	PCE
  Number of Units in Package 1	1
  Package 1 Height	49.4 cm
  Package 1 Width	18.5 cm
  Package 1 Length	41.5 cm
  Package 1 Weight	7.31 kg
  Unit Type of Package 2	PAL
  Number of Units in Package 2	70
  Package 2 Height	132.5 cm
  Package 2 Width	100 cm
  Package 2 Length	120 cm
  Package 2 Weight	510.86 kg
  SCC14	10731304219788
  Contractual warranty
  Warranty	2 years repair or replace

• Description	Downloads
  BK650EI:Datasheet	Download
  BK650EI:User Guide	Download
