Alogic DUPRMX3-WW MX3 USB-C Triple Display DP Alt. Mode Docking Station – With 100W Power Delivery

• Description
• Specifications
• Downloads

• Alogic DUPRMX3-WW MX3 USB-C Triple Display DP Alt. Mode Docking Station – With 100W Power Delivery

  SIMPLIFIED CONNECTIVITY- DP Alt. Mode Technology
  The MX3 makes multi-display set ups simple. Featuring DP Alt Mode technology, it connects directly with up to three displays and multiple other accessories. No need to install drivers or software. Plug in and go.

  SINGLE 5K DISPLAY WITH MAC
  The MX3 is a powerful docking station for Mac users seeking to add a dazzling, ultra-high resolution display for their desk set up.

  TRIPLE 4K DISPLAYS WITH WINDOWS
  Windows users can plug into the MX3 to run up to three ultra-high resolution external displays.

  11 HIGH-PERFORMANCE PORTS
  USB-A 3.1 Gen 1 (5G) BC 1.2 & Apple Charging Support connects with older laptops and charges Apple device
  USB-C 3.1 Gen 2 (10G) BC 1.2 & Apple Charging Support connects with modern laptops and charges Apple devices
  Micro SD Card Reader (SD 4.0) for speedier downloads
  SD Card Reader (SD 4.0) for speedier downloads
  3.5mm TRRS Audio/Microphone Jack supports quality recording and playback
  RJ45 Ethernet 1 Gbps for speedy data transfer
  DisplayPort (DP1.4/DP++) for generous bandwidth data transmission
  DisplayPort (DP1.4/DP++) for generous bandwidth data transmission
  DisplayPort (DP1.4/DP++) for generous bandwidth data transmission
  SB-A 3.1 Gen1 (5G) works with older laptops
  USB-A 3.1 Gen1 (5G) works with older laptops

• Specification	Details
  SKU	DUPRMX3-WW
  Barcode (EAN)	9350784023834
  Displays	Single display, Dual display, Triple display
  Host Connection Technology	USB-C
  Mac Processor Type	M1/M2, M1/M2 Ultra/Pro/Max, Intel
  Display supported on Mac M1/M2	Single display
  Display supported on Mac M1/M2 Ultra/Pro/Max	Single display
  Display supported on Windows	Single display, Dual display, Triple display
  Docking Station Type	Desktop
  Warranty	2 Years
  Physical Characteristics	Product Dimensions: 190 x 90 x 26.5mm (W x D x H) <br> Colour: Space Grey and Black <br> Weight: 535g <br> Materials: ABS
  Additional Features	Ethernet, 3.5mm Audio, Card Reader
  Compliance	FCC, CE, RoHS
  Resolution	Up to 2 x 4K UHD 60Hz or 3 x 4K UHD 30Hz with DP 1.4 HBR3 DSC enabled host* <br> *See resolution support table below for maximum outputs
  Input	1 x USB-C Port
  Output	3 x DisplayPort (DP1.4/DP++) <br> 1 x USB-C 3.1 Gen 2 (10G) BC 1.2 and Apple Charging Support <br> 1 x USB-A 3.1 Gen 1 (5G) BC 1.2 and Apple Charging Support <br> 2 x USB-A 3.1 Gen1 (5G) <br> 1 x 3.5mm TRRS Audio / Microphone Jack <br> 1 x RJ45 Ethernet 1Gbps <br> 1 x SD Card Re
  Device Compatibility	Apple, Microsoft
